本噴砂機適用于10-490mm孔徑的各種產品的內部因素和界面手工藝操作步驟噴砂做業,清理外界面的黑垢、界面去銹、界面增強、提高自己粗燥度、我們要除界面壓力等。(如:電飯煲、杯具、不粘鍋、蘋果手機表殼、臺式電腦表殼、水輪、切割片一系列)可按客必須訂做單車間工作臺或雙車間工作臺。
The sandblasting machines apply to 10-490 mm diameter of of all kinds of the internal and external surfaces of the manual operation sandblast homework, remove the dirt, surface derusting appearance, surface strengthening and improving roughness, removing surface stress, etc. (for example: electric meal bao, cup with, titanium, cell phone casing, computer shell, impeller, saw blades, etc) make single or double position according to customers' special requirements.
◆主要的技術工藝性能參數 Main technical parameters
絲機具體型號 Model |
STR-A1500型12槍圓板傾動式 |
STR-A1600型八槍圓球轉臂式 |
STR-A1600型十四槍圓筒傾動式 |
服務器外形尺寸 Complete machine size(mm) |
1500×2160×3000 |
1600×1800×2500 |
2200×2400×3000 |
運轉艙厚度 Working class size(mm) |
Φ1400 |
Φ1500 |
Φ2000 |
排塵箱尺碼 Dedust box sizes(mm) |
1000×1200×2500 |
1000×1200×2500 |
1400×1400×2500 |
小轉盤數 The small turntable for |
16個 |
8個 |
8個 |
噴槍數 Gun number |
12把 |
8把 |
14把 |
主機電源 Power |
380V單相電 |
380V380V電 |
380V三相電機電 |
照明 Floodlight |
2盞防震燈 |
2盞防爆設備燈 |
2盞防暴燈 |
產品承重 Machine weight |
800kg |
750kg |
800kg |
